17 Specifications
154 Trimble R7/R8 GPS Receiver User Guide
Trimble R8 Operation
17.4 Technical Specifications
Table 17.3 lists technical specifications for the Trimble R8 receiver.
Table 17.3 Technical specifications
Feature Specification
Tracking 24 Channels L1 C/A Code, L2C, L1/L2 Full Cycle
Carrier, WAAS/EGNOS support
Fully operational during P-code encryption
WAAS satellite tracking
Signal processing Maxwell V architecture
Very low-noise C/A code processing
Multipath suppression
Start-up Cold start: < 60 seconds from power on
Warm start: < 30 seconds with recent ephemeris
Initialization Automatic while moving or static
Minimum
initialization time
10 sec + 0.5 × baseline length (km)
Communications Two RS-232 serial ports (Port 1, Port 2,)
Port 1: Baud Rates up to 115,200 bps
Port 2: Baud Rates up to 115,200 bps
RTS/CTS flow control negotiation supported on Port 2
only
Bluetooth communications with Trimble ACU or TSCe
with Bluecap module
