19 Cables and Connectors
162 Trimble R7/R8 GPS Receiver User Guide
Trimble R8 Operation
19.1 Introduction
This chapter provides pinout information for the Trimble R8 receiver
standard and optional cables. This information can be used to prepare
special cables for connecting the receiver to devices and instruments
not supported by the standard and optional cables.
19.2 Port 1 and 2 Connectors
Figure 19.1 shows the location of the Trimble R8 serial ports.
Figure 19.1 Trimble R8 serial ports
1
2
BARCODE S/N LABEL
Port 1
Port 2
