Trimble R7/R8 GPS Receiver User Guide 163
Cables and Connectors 19
Trimble R8 Operation
Figure 19.2 gives pinout requirements for the connector labeled
Port 1.
Figure 19.2 Port 1 connector
Figure 19.3 gives pinout requirements for the connector labeled
Port 2.
Figure 19.3 Port 2 connector
7
1
3
6
4
2
5
Pins 9 8 7 6
Pins 5 4 3 2 1
