Triple E COMMANDER - Sleeping Facilities

13-10
COMMANDER / EMBASSY
2-1.
Sofa/Bed Conversion:
The front sofa converts into a bed. To convert
to bed:
a. Lift the sofa seat up from the base.
b. Pull forward until the back drops down to
a bed position.
To convert back to a sofa:
a. Lift and push the sofa back against the
wall.
On the Commanders, the sofa has a convenient
drawer located below, on the Embassy there is
open storage under the sofa.
2-2.
Hide-a-Bed:
a. Move the cocktail chair as far back as
possible.
b. Remove the hide-a-bed cushions.
c. Release the safety latch and lift out the
bed by pulling up on the centre of the
front bar and fold it open.
3.
Dinette (Optional):
The dinette also can be converted into a bed:
a. Remove cushions.
b. Lift table and remove the table legs.
c. Drop table between seats so that the
edge of the table rests on seat edge sup-
ports.
d. Arrange cushions for form a bed, placing
Fig. 13-12 DINETTE/BED
Fig. 13-11 EMBASSY HEATER SWITCH
13.13 SLEEPING FACILITIES
Do not use sleeping facilities while motorhome is
in motion.
WARNING
1.
Bedroom Heater (Commander and Embas-
sy XL only):
Standard sleeping facilities with a bed are
located at the rear of the coach. The control
for the Embassy heater are as shown in fi gure
13-11 and is “push/pull” operation. The Com-
mander has a switch on the dashboard to
control the heater.
To convert back to a dinette, reverse the above
instructions.
