Triple E COMMANDER - Electric Step (Optional on Embassy); Screen Windows; Coffee Maker (Optional)

13-13
COMMANDER / EMBASSY
13.15 ELECTRIC STEP (OP-
TIONAL ON EMBASSY)
Fig. 13-14 STEP
13.17 COFFEE MAKER
(OPTIONAL)
See the instruction manual in your information
packet.
Fig. 13-16 COFFEE MAKER
Fig. 13-15 SCREEN WINDOWS
Periodic maintenance including lubrication and
cleaning are necessary to keep the step function-
ing properly.
See manufacturer's manual for operating instruc-
tions.
Normal Operation - Step switch in “on” position (located
on switch panel beside door entrance). Open the door.
The step should descend and lock in extended position
with the understep light on. Close the door. The step
should retract and lock in up position.
1.
Step Locked in Down Position:
Open the door and allow step to descend. Flip
switch to off. The step should remain in down posi-
tion with the understep light off when the door is
closed.
2.
Step Locked in Up Position:
Flip switch off while door is closed and step is
locked in up position.
3.
Ignition Safety System:
When the ignition switch is turned on, step will acti-
See manufacturer's manual for operating instruc-
When the ignition switch is turned on, step will acti-
See manufacturer's manual for operating instruc-
tions.
When the ignition switch is turned on, step will acti-
tions.
vate with door movement, regardless of door switch
tions.
vate with door movement, regardless of door switch
tions.
position.
13.16 SCREEN WINDOWS
The screen windows have been designed
so that the screen may be removed. To
remove the screen, push it up and pull it.
