Fig. 4-7 CO-PILOT SEAT CONTROL (TYPICAL)
Fig. 4-7 CO-PILOT SEAT CONTROL (TYPICAL)
4.4 DRIVERS/CO-PILOT SEAT
1.
Forward-Back Position:
B
oth the drivers and co-
pilot seats are designed with a sliding base to
allow the seat to be moved forward or
backward for occupant com-
fort.
a.
Commander:
A spring loaded latch is located at the end of the
left hand arm rest to release the sliding base.
Pull up on the latch to release the lock. Slide
the seat as desired and lock it in position.
b.
Embassy:
The spring loaded latch is located on the front
underneath the seat. Push the lever left to
release the lock. Slide the seat as desired and
release the lever to lock the seat into position.
2.
Swivel Lock:
Both the drivers and co-pilot seats
are designed with a swivel base to allow the seat to
be used for driving or as part of the living room.
a.
Commander:
A spring loaded latch is located at the end of
the right hand arm rest to release the swivel
lock. Pull up on the latch to release the lock.
Swivel the seat as desired. When the seat is
turned in the direction of travel, the swivel lock
will automatically engage and secure the seat.
Do not move the vehicle unless the drivers and
co-pilots seats are locked in the forward facing
direction. One some fl oorplans the seat may
have to be moved to the most forward position
to rotate it.
b.
Embassy:
The spring loaded latch is located at the right
side underneath the seat. Push the lever back
to release the lock. Swivel the seat as desired.
When the seat is turned in the direction of
travel, the swivel lock will automatically engage
and secure the seat. Do not move the vehicle
unless the drivers and co-pilots seats are locked
in the forward facing direction.
3.
Back Rest Angle:
This spring loaded lever controls the lock on the
back rest angle position mechanism. Pull the lever
up and hold to release the position lock. Gently
lean back to push the back rest down. Lean forward
2
1
3
COMMANDER
EMBASSY
3
1
2
