Triple E COMMANDER - Slide-Out Room (Slide-Out Equipped Models Only)

4-25
COMMANDER / EMBASSY
Left
Right
Fig. 4-34 ROOM LOCKS
Fig. 4-33 CONTROL PANEL
1.
Control Panel :
This panel controls the operation of the
slide-out room in the motorhome. Review
the extend/retract procedure before operat-
ing these controls.
a.
Key Switch:
This key switch controls the power to
the pump that supplies pressurized oil
to the hydraulic cylinders that extend
and retract the room. Always turn the
switch off unless moving the slide-out
room. See section 9.3.1 for detailed
information about the slide out room
operation.
b.
Extend/Retract:
This spring-loaded to center neutral
rocker switch controls the movement
and direction of the slide-out room.
Depress and hold the top portion of the
switch to extend the room. Depress and
hold the bottom portion of the switch to
retract the room. Release the switch for
it to return to centre and the room will
stop moving.
2.
Slide-Out Room Locks:
This slide-out room assembly is designed
with locks that hold it securely in place for
transport. Embassy: located at the ceiling of
the room on each end, Commander: located
on the fl oor. Turn clockwise to secure lock
and counterclockwise to release. Always
4.18 SLIDE-OUT ROOM (SLIDE-OUT EQUIPPED MODELS ONLY)
IMPORTANT
Release the switch when the extend/
retract cylinders reach the end of their
stroke. The pressure of the hydraulic
circuit will change when the cylinders
reach the end of their strokes and the
pump sound will change. Release the
switch when the sound changes.
CAUTION
Extend levelling jacks on to a fi rm
supporting base and level unit
before extending room.
NOTE
Refer to section 9.3 for detailed
operating instructions.
a
b
operation.
Make sure travel locks are removed
before extending the slide-out.
Make sure travel locks are fastened se-
curely before moving the motorhome.
WARNING
