10.1.2 POWER CONTROL CENTER - COMMANDER ONLY (OPTIONAL)
Fig. 10-2 POWER PANEL (OPEN DOORS)
This panel contains the fuses for the 12 volt sys-
tem, circuit breakers for the 120 volt system. 120V
power to 12V DC converter is mounted in compart-
10.1.3 120-VOLT CIRCUIT BREAKERS
The breaker panel protects all 110-volt equip-
ment and components in the motorhome from
overload, from a short in the wiring or a short
in the component itself. This cuts off the fl ow
of electricity in the system and prevents dam-
If a breaker “trips”, allow a brief “cool down”
period and then reset the breaker by turning it
OFF and then ON. If a breaker “trips” again,
this could mean that there is a short in the
wiring or in the equipment and both should be
checked and serviced by a qualifi ed techni-
There is a singular panel switch of either 30
or 50 amps which protects the entire electri-
cal system. Become familiar with the loca-
tions of the main 110v breaker and check it
fi rst if electrical problems should be experi-
Refer to control panel manuals for more
Fig. 10-3 120-VOLT CIRCUIT BREAKERS
