4.7 FRONT UPPER CABINETS
Certain pieces of entertainment equipment are
installed inside the front upper cabinets for conven-
ience and looks.
1.
Center:
A.
VCR (Optional):
This is a standard VCR and is a part of the
vehicle entertainment system. Refer to the
instructions in the information package for
details. Close the cabinet door when VCR
access is not required.
B.
Input Selector:
An input channel selector is located on top
of the VCR and is used to select a specifi c
signal to each TV in the vehicle or the
VCR.
TV1
a.
ANT:
This push button switch selects the
external antenna as the source of the
input signal to TV 1 or the one mount-
ed in the front console.
b.
AUX:
This push button switch selects the
auxiliary signal, normally cable, as the
source of the input signal to TV 1 or
the one mounted in the front console.
c.
VCR:
This push button switch selects the
VCR output as the source of the input
signal to TV 1 or the one mounted in
the front console.
COMMANDER / EMBASSY
Fig. 4-11 TV INPUT SELECTOR AND VCR (COMMANDER ONLY)
VCR
a.
ANT:
This push button switch selects the
antenna signal and directs it into the
VCR.
b.
AUX:
This push button switch selects the
auxiliary signal, normally the external
cable input, and directs it into the VCR.
TV2
a.
ANT:
This push button switch selects the
external antenna as the source of the
input signal to TV 2 or the one mount-
ed in the bedroom.
b.
AUX:
This push button switch selects the
auxiliary signal, normally cable, as
the source of the input cable to TV-2
(bedroom).
c.
VCR:
This push button switch selects the
VCR output as the source of the input
signal to TV 2(bedroom).
