7. Using the External Computer Data Link
The MicronNav data can be made available for use by third party software packages running
on an external PC and this section gives details on how to set this up. The external computer
data link should be connected as detailed in Section 3.1, “Preparation”
The following list of output strings are currently available:
• Tritech proprietary strings:
• ‘Raw XYZ’
• ‘Proc XYZ’
• Third party strings:
• ‘TP-2EC’ (Trackpoint)
• ‘HPR 300P’
• ‘HPR 410’ (Simrad HPR)
• NMEA ‘$GPGGA’ (Lat/Lon Fix Data)
• NMEA ‘$GPGLL’ (Lat/Lon Position)
• NMEA ‘$GPRMC’ (Lat/Lon Fix Data)
• NMEA ‘$RATTM’ (Tracked Target Message for charting packages)
• ‘$PSIMSSB’ (Simrad)
• '$GPDBT' (Depth Below Transducer = USBL 'Z' co-ordinate)
Support for Tritech International Ltd proprietary strings Short and Long is planned for future
releases.
Note
Other third party industry standard strings may be added at customer request.
7.1. Setting the RemV4 string output
To select the output string format in RemV4:
Note
Up to 4 Output strings can be selected which can be output on the same COM
port or a different one.
1. Ensure ‘Seanet Pro’ is opened and has an Application containing ‘Nav’ in the name
running. This will ensure the Slot list (‘Applications’ – ‘Remote SKV4’) of RemV4 is built
with the Nav slot (=8) listed.
2. Click on the ‘Configure’ drop-down button for the Nav item (Slot 8) and select ‘Output 1’
as shown below.
