When multi -head cutting, users should do some settings (take two-head
cutting as example):
1. Enable【Z AutoReset】function, and set【Head Count】to “2”.
2. Reset the machine, make Laser head1 and Laser head2 laser by press
【Laser】on the panel, and mark these two points, then measure the
distance between these points, the distance is the【ZX Head Space】.
3. Enter the Z Axis Parameters page, and set the distance per pulse of Z
axis. Please refer to the Chapter 3.5 to know more about the
calculation.
4. When multi-head cutting, the graphics in LaserCAD are dashed. If the
graphics are solid lines, the Laser head1 (main laser head) will cut all
the file, and the Laser head2 won’t cut. If the number of graphics in
single lines is odd, the system defaults to cutting even numbers of
graphics with laser head1 and odd numbers of graphics with laser
head2, like Figure 7-6-4. If the number of graphics in single line is even,
the system defaults to cutting the same number of laser heads 1 and 2,
as shown in Figure 7-6-5.
