start, please make sure to enable the axis auto reset function. Detail
settings refer to Chapter 7.4.
3.4 Key Direction
On the main page, press【↑】【↓】【←】【→】to move motion axis, and
check whether the motion direction is the same as key direction. If not,
please modify the【Key Direction】on the axis parameters page.
3.5 Distance Per Pulse
Distance per pulse refers to the actual distance of motion axis for each
pulse instruction sent by the controller.
1. Distance per pulse of X
1) Open the【XY AutoReset】function, and reset machine, then mark
the current position of laser head with A.
2) On the main page, press【Menu】and enter the Jog Control page.
Set the【Jog Distance】to 200mm as example. Then press【Enter】
to save your modification. If you did not set the【Range】on Axis
Parameters page, please do not set the【Jog Distance】value too
large.
3) On the Jog Control page, move cursor to【X/Y Jog】, then press
direction key (【←】/【→】) one time to make the laser head move
a jog distance on the X direction. Mark the current position of laser
head with B.
