AWC708C PLUS Motion Control User Manual
WWW.SZTROCEN.COM
93
Figure7-3-1 I/O Parameters Interface
Table7-3-1 I/O Parameters Instruction
Name
Instruction
Foot Switch
Enable or disable the foot switch function.
Open Protection
Enable or disable the open protection function.
Feed Switch
Enable or disable the feed function.
Input Valid Level
Set input IO to low level or high level.
7.4 Auto Reset Settings
On the Manufacture Params Settings page, move cursor to【Auto Reset
Settings】and press【Enter】. Press【↑】【↓】to move cursor, press【←】
【→】to modify options and press【Enter】to save settings.

Trocen AWC708C Plus Specifications

General

Model	AWC708C Plus
Supported Laser Types	CO2 Laser
Communication Interface	USB, Ethernet
Control Software	LaserCAD
Compatible Operating Systems	Windows XP/7/8/10
Operating Voltage	24V DC
Control Signal	PWM
Axes	3
File Format	DST, PLT, BMP, DXF, AI
Control System	DSP
Input Voltage	DC 24V
