6.7.5 CCD Config
On the Common Params Settings page, move cursor to【CCD Config】and
press【Enter】. Press【↑】【↓】to move cursor, press【←】【→】to
modify options and press【Enter】to save settings.
Figure6-7-12 CCD Config
Table6-7-5 CCD Config Instruction
Name
Instruction
CCD Fun
The switch of CCD function.
Connect Type
Set USB or network connection type.
Data Error Check
Check if the Mark points in the file loaded are the same with
camera.
