1.5.3 Number Keys
Used to modify parameter values. 【0】and【C】keys also can be used
to move feeding axis (U axis).
1.6 Wiring Board
The panel and other parts of machine are connected by wiring board. The
components as below:
⚫ Connect motor driver
⚫ Detection of motion axis limit signal
⚫ Input signal detection
⚫ Output IO control signal and corresponding power supply
