6.7.4 Rotate Engraving & Cutting
On the Common Params Settings page, move cursor to【Rotate Engraving
& Cutting】and press【Enter】. Press【↑】【↓】to move cursor, press
【 ← 】【 → 】 to modify options and press number keys to modify
parameters, press【Enter】to save settings.
Fiugre6-7-8 Rotate Engraving & Cutting Interface
Table6-7-4 Rotate Engraving & Cutting Instruction
Name
Instruction
Rotary
Enable or Disable rotary engraving function.
Rotary Axis
The axis which rotary engraving uses.
Pulse Count Per
Rotate
The pulse parameters for the motor to make the rotary axis
rotate one circle.
