3.6 Hard Limit and Range
On the main page, press【Stop】+【Shift】at the same time to open the
Manufacture Params Settings page. Then move cursor to【HardLimit
Settings】and press【Enter】, users can enable or disable the hard limit
parameters. AWC708C PLUS supports range function, so users do not need
to install hard limit sensors, just setting【Range】parameters on the
relevant axis parameters page will be enough.
Set the distance per pulse of X/Y/Z/U axis according to the content of the
Chapter 3.5. Then move motion axis to the maximum distance towards
positive direction. You can set the coordinate value on the panel as
【Range】.
