7.7 Function Config
On the Manufacture Params Settings page, move cursor to【Function
Config】and press【Enter】. Press【←】【→】to modify options and press
【Enter】to save settings.
Figure7-7-1 Function Config Interface
Table7-7-1 Function Config Instruction
Name
Instruction
Z-Axis for Autofocus
The switch of Z-axis Autofocus. If you need Z AutoFocus
function, you need to enable this option. This parameter is
mainly to control the distance between laser head and
working platform.
U-Axis For Feeding
Enable or disable the function. Enable this function, U axis
will work as feed axis.
