4) Measure the distance between A and B, then input the value into
【Actual Length】.
5) On the main page, press【Stop】+【Shift】at the same time to open
the Manufacture Params Settings page. Then move cursor to【Axis
Parameters】option and press【Enter】. Then open the X Axis
Parameters page and move cursor to【Distance Per Pulse】, press
【Enter】. Input 200mm into【Expected Length】and input the
distance between A and B into【Actual Length】. Then press【Enter】,
the distance per pulse of X axis will be calculated.
6) The calculation methods of distance per pulses of Y and U axis are
the same as X axis.
7) When Z axis works as lifting shaft or platform lifting shaft, the
calculation method of distance per pulse is the same as X axis.
2. Distance per pulse of Z axis (when two-head working)
When the machine does multi-head cutting, the distance per pulse of
Z axis is calculated as below:
1) Open the【Z AutoReset】function, and reset machine. Press【Laser】,
then mark the laser head2 position with A.
2) On the main page, press【Menu】and enter the Jog Control page.
Set the【Jog Distance】to 200mm as example. Then press【Enter】
to save your modification. If you did not set the【Range】on Axis
Parameters page, please do not set the【Jog Distance】value too
large.
