and if the laser light control signal is high level, connect the H pin of laser
power.
1.6.2.6 Motor Drive Control Port
The wiring board can provide up to 6 motor driver connections, and users
can choose step driver or servo driver according to the need. The servo
driver has higher control accuracy than step driver. Users can choose the
appropriate driving mode according to the usage scenario, cutting
precision requirements and cost factors. We take the step driver as an
example. Various types of servo driver wiring diagram, please refer to
Appendix 1 of this article.
Table1-6-6 Motor Driver Connection Instruction
PIN
Name
Instruction
X
1
DC5V
Output DC voltage (5V)
2
PUL
Pulse signal
3
DIR
Direction signal
Y
1
DC5V
Output DC voltage (5V)
2
PUL
Pulse signal
3
DIR
Direction signal
Z
1
DC5V
Output DC voltage (5V)
2
PUL
Pulse signal
