AWC708C PLUS Motion Control User Manual
Max Power1
Min Power1
Max Power2
Min Power2
Displays the Max & Min power of laser 1 and 2. Max power
means working power. Min power means turning power. During
cutting process, if the cutting lines is uneven (different cutting
depth), the maximum and minimum power of laser head should
be adjusted to ensure the best cutting effect. If the maximum
and minimum power is set too high, the cutting material may be
damaged. If set too low, may cause incomplete cutting. Users
shall set appropriate maximum and minimum power values
according to different cutting materials.
Max Power3
Min Power3
Max Power4
Min Power4
Press【Shift】on the main page to switch 1/2 to 3/4 laser power.
Displays the Max & Min power of laser 3 and 4. Max power
means working power. Min power means turning power. During
cutting process, if the cutting lines is uneven (different cutting
depth), the maximum and minimum power of laser head should
be adjusted to ensure the best cutting effect. If the maximum
and minimum power is set too high, the cutting material may be
damaged. If set too low, may cause incomplete cutting. Users
shall set appropriate maximum and minimum power values
according to different cutting materials.
Displays the amount of time worked with this task.
Displays the machine state. Includes working state, idle state,
pause state. There will be a percentage to show the working
