Trocen AWC708C Plus - 6.7.3 Axis Speed Parameters

AWC708C PLUS Motion Control User Manual
WWW.SZTROCEN.COM
74
Config】) and set【AutoFocus Distance】here to keep the distance between
laser head and working table.
Fiugre6-7-6 Common Parameters Interface
Table6-7-2 Common Parameters Instruction
Name
Instruction
Auto Focus Distance
(mm)
The distance between the laser head and working
platform.
Key Move Speed
(mm/s)
The motion speed of axis when press the direction keys on
panel.
Run Box Speed
(mm/s)
The speed at which the laser head runs along the outer
frame of graphics without laser output.
Cut Box Speed
The speed at which the laser head cuts along the outer
