Trophy 1703 - 2103 Exterior Hull Views

12
Chapter 3: Locations Center Console Models • Owner’s Manual Supplement
2103 Exterior Hull Views
PORT HULLSIDE
STARBOARD HULLSIDE
BOW EYE
FUEL TANK
BAITWELL FISH BOX
DRAIN
VENT
STERN EYES
BILGE DRAIN
DECK
FORWARD BILGE
PUMP DRAIN
AFT BILGE
PUMP DRAIN
HOLDING TANK VENT
(IF EQUIPPED)
TRANSOM
FRESHWATER TANK VENT
DRAIN
DECK DRAINS
PLUG
TRIM TAB
DRAINS
(IF EQUIPPED)
TRIM TAB
(IF EQUIPPED)
