Chapter 3: Locations Center Console Models • Owner’s Manual Supplement
1703 Helm View
1903 Helm View
COMPASS
GRAB RAIL
SHIFT/THROTTLE
LEVER
NAVIGATION
HORN
LIGHTS
12-VOLT
DC OUTLET
ACCESSORY
SWITCHES
BAITWELL
PUMP
BILGE
PUMP
TACHOMETER, FUEL,
& VOLTMETER GAUGE
IGNITION SWITCH
EMERGENCY ENGINE
KILL SWITCH
STORAGE
COMPARTMENT
NOTE: TYPICAL HELM LAYOUT SHOWN. ACTUAL LAYOUT MAY
VARY DEPENDING ON ENGINE AND ACCESSORY OPTIONS.
GRAB HANDLE
12-VOLT DC
PUSH-TO-RESET
CIRCUIT BREAKERS
GRAB RAIL
SHIFT/THROTTLE
LEVER
NAVIGATION
LIGHTS
ACCESSORY
SWITCHES
BAITWELL
PUMP
BILGE
PUMP
HORN
12-VOLT
DC OUTLET
TACHOMETER, FUEL,
& VOLTMETER GAUGE
SPEEDOMETER,
TEMPERATURE,
& TRIM GAUGE
IGNITION
SWITCH
EMERGENCY ENGINE
KILL SWITCH
COMPASS
STORAGE
COMPARTMENT
NOTE: TYPICAL HELM LAYOUT SHOWN. ACTUAL LAYOUT MAY
VARY DEPENDING ON ENGINE AND ACCESSORY OPTIONS.
12-VOLT DC
PUSH-TO-RESET
CIRCUIT BREAKERS
