39
Center Console Models • Owner’s Manual
Supplement
Chapter 4: Propulsion & Related Systems
Fuel Fill & Vent
• The fuel fill deck fitting is marked GAS.
• If you have problems filling the fuel tank, see if the fuel fill hose or fuel tank vent hose is kinked or collapsed.
• If there are no visible signs of a problem, contact your local dealer.
Fuel Filters
• The fuel pickup tube, located inside the fuel tank, is equipped with a fine mesh screen filter.
• Also, when supplied by the engine manufacturer, a fuel filter is installed on the engine(s).
• Periodically replace the fuel filters to make sure they remain clean and free of debris.
• Talk to your selling dealer or local marina about fuel additives that help prevent fungus or other buildup in your
fuel tank.
FUEL TANK FUEL TANK
VENT HOSE
FUEL FEED
HOSE
FUEL FILL
DECK FITTING
FUEL TANK
FUEL FEED
HOSE(S)
FUEL FILL
DECK FITTING
FUEL LEVEL
SENDING UNIT
FUEL TANK
VENT FITTING
2103 FUEL SYSTEM
2503 FUEL SYSTEM
