Trophy 1703 - 2503 Single Engine Helm View; 2503 Twin Engine Helm View

20
Chapter 3: Locations Center Console Models • Owner’s Manual Supplement
2503 Single Engine Helm View
2503 Twin Engine Helm View
SHIFT/THROTTLE LEVER
COMPASS
GRAB RAILS
TRIM TAB SWITCHES
STORAGE
COMPARTMENT
HORN
NAVIGATION LIGHTS
FORWARD BILGE PUMP
AFT BILGE PUMP
SEAWATER WASHDOWN
FRESHWATER PUMP
ACCESSORY
COURTESY LIGHTS
12-VOLT DC OUTLET
SPEEDOMETER, VOLTMETER
& TEMPERATURE GAUGE
TACHOMETER,
TRIM & FUEL GAIGE
(IF EQUIPPED)
BAITWELL PUMP
PUMP
(IF EQUIPPED)
SMART CRAFT GAUGE
(IF EQUIPPED)
NOTE: TYPICAL HELM LAYOUT SHOWN.
ON ENGINE AND ACCESSORY OPTIONS.
ACTUAL LAYOUT MAY VARY DEPENDING
WINDLASS SWITCH
(IF EQUIPPED)
12-VOLT DC
PUSH-TO-RESET
CIRCUIT BREAKERS
IGNITION SWITCH &
EMERGENCY ENGINE
KILL SWITCH
SHIFT/THROTTLE
LEVERS
COMPASS
SPEEDOMETER,
GRAB RAIL
HORN
NAVIGATION LIGHTS
FORWARD BILGE PUMP
AFT BILGE PUMP
BAITWELL PUMP
FRESHWATER PUMP
ACCESSORY
COURTESY LIGHTS
12-VOLT DC OUTLET
VOLTMETER & FUEL GAUGE
TRIM TAB SWITCHES
TACHOMETER, TRIM
& TEMPERATURE GAUGE
(IF EQUIPPED)
SEAWATER WASHDOWN
PUMP
(IF EQUIPPED)
SMART CRAFT GAUGE
(IF EQUIPPED)
IGNITION SWITCHES &
EMERGENCY ENGINE
NOTE: TYPICAL HELM LAYOUT SHOWN.
ON ENGINE AND ACCESSORY OPTIONS.
ACTUAL LAYOUT MAY VARY DEPENDING
WINDLASS SWITCH
(IF EQUIPPED)
STARBOARD ENGINE
GRAB RAIL
TACHOMETER, TRIM
& TEMPERATURE GAUGE
PORT ENGINE
12-VOLT DC
PUSH-TO-RESET
CIRCUIT BREAKERS
KILL SWITCHES
