Chapter 7: Plumbing Center Console Models • Owner’s Manual
Supplement
Drain Systems
• The deck, fish boxes, storage
boxes and sink (2503 only) are
above the waterline and are
gravity drained overboard.
• Keep the drains free of debris.
NOTE: VIEWS ARE UNDERSIDE OF DECK
DECK
DRAINS
SINK
DRAIN
1703 & 1903 DECK DRAINS
2103 DECK DRAINS
2503 DECK & GRAY WATER DRAINS
DECK DRAINS
DECK DRAINS
