Trophy 1703 - 2103 Helm View

19
Center Console Models • Owner’s Manual Supplement Chapter 3: Locations
2103 Helm View
GRAB RAIL
SHIFT/THROTTLE
LEVER
EMERGENCY ENGINE
KILL SWITCH
GRAB RAIL
COMPASS
ALL-ROUND LIGHT
NAVIGATION LIGHTS
ACCESSORY SWITCHES
BAITWELL PUMP
HORN
FORWARD BILGE PUMP
AFT BILGE PUMP
FRESHWATER PUMP
(IF EQUIPPED)
INSTRUMENT LIGHTS
COURTESY LIGHTS
12-VOLT DC OUTLET
SPEEDOMETER,
TEMPERATURE,
& TRIM GAUGE
STORAGE
COMPARTMENT
SEAWATER WASHDOWN
PUMP
(IF EQUIPPED)
NOTE: TYPICAL HELM LAYOUT SHOWN.
ON ENGINE AND ACCESSORY OPTIONS.
ACTUAL LAYOUT MAY VARY DEPENDING
12-VOLT DC
PUSH-TO-RESET
CIRCUIT BREAKERS
12-VOLT DC
PUSH-TO-RESET
CIRCUIT BREAKERS
TACHOMETER, VOLTMETER,
& FUEL GAUGE
IGNITION SWITCH
