Chapter 7: Plumbing
Bilge Pump(s)
• Your boat is equipped with one or
more bilge pumps for pumping water
out of the bilge.
• The autofloat switches, mounted next
to the bilge pump(s), will turn On the
bilge pump(s) if bilge water rises
above a preset level.
• You can also turn On the bilge
pump(s) yourself using the switch(es)
at the helm.
• The bilge pump(s) is wired directly to
the battery. Unless the battery is dead,
the bilge pump system should work
even when your boat is unattended.
NOTICE
Discharge of oil, oil waste, or fuel into navigable waters is prohibited by law. Violators are sub-
ject to legal action by the local authorities.
BILGE PUMP &
AUTOFLOAT SWITCH
THRU-HULL
FORWARD BILGE PUMP
& AUTOFLOAT SWITCH
THRU-HULL
AFT BILGE PUMP &
AUTOFLOAT SWITCH THRU-HULL
2103 BILGE PUMP SYSTEM
1703 & 1903 BILGE PUMP SYSTEM
THRU-HULL
FORWARD BILGE PUMP
& AUTOFLOAT SWITCH
THRU-HULL
AFT BILGE PUMP &
AUTOFLOAT SWITCH
2503 BILGE PUMP SYSTEM
