Center Console Models • Owner’s Manual
Supplement
Chapter 11: Electrical System
Battery System - 2103
ENGINE
BATTERIES
NEGATIVE
POSITIVE
BATTERY
SWITCH
GROUNDING
BLOCKS
POSITIVE BATTERY CABLES ARE RED
NEGATIVE BATTERY CABLES ARE YELLOW
