Chapter 7: Plumbing Center Console Models • Owner’s Manual
Supplement
Autofloat Switch(es)
• The autofloat switch(es) turns the bilge pump(s) On when water rises above a preset level.
• Test each autofloat switch often.
Autofloat switch testing:
1. Lift the autofloat switch test but-
ton to turn On the bilge pump.
• If the pump does not turn On, check
the fuse on the fuse block or the
push-to-reset circuit breaker.
• If the fuse or circuit breaker is
good, but the switch still does not
work, it may mean the switch is bad
or, the battery is dead.
2. After testing, push the test button
all the way down to reset auto
mode.
PUSH TEST BUTTON DOWN
LIFT TEST BUTTON UP
(BILGE PUMP SHOULD TURN ON) (BILGE PUMP SHOULD TURN OFF)
AUTOFLOAT SWITCH
TEST BUTTON
TESTING
When the test is completed on each float switch, you MUST push the test button ALL THE
WAY DOWN to reset auto mode!
CAUTION
!
