75
Center Console Models • Owner’s Manual
Supplement
Chapter 11: Electrical System
12-Volt DC Dash Harness - 2103
12-Volt DC Dash Harness - 2503
COMPASS
DASH PANEL
IGNITION PANEL
SHIFT/THROTTLE
LEVER
HORN
TO DECK HARNESS
HORN
COMPASS
SWITCH PANEL
SHIFT/THROTTLE
GAUGE PANEL
DASH LIGHT
TRIM TABS
HEAD LIGHT
FUSE BLOCK
GROUND BUSS
MAIN POWER STUD
HEAD LIGHT
