Trophy 1703 - Battery Switch Positions (2103 & 2503 Only); Fuses & Circuit Breakers

65
Center Console Models • Owner’s Manual Supplement Chapter 11: Electrical System
Battery Switch Positions (2103 & 2503 Only)
2103 Battery Switch Positions
2503 Battery Switch positions
Fuses & Circuit Breakers
• Circuit breakers for engines and main accessory power are on the 12-volt DC push-to-reset circuit breaker panel
and on the battery switch panel.
• For the locations of the battery switch panel and the 12-volt DC push-to-reset circuit breakers, see the Component
Locations section in Chapter 2 of this supplement.
NOTE: Some equipment may have secondary fuse protection at the unit, behind the battery switch panel, or at
the batteries.
BATTERY SWITCH
POSITIONS
ENGINE
STARTING
ACCESSORIES & LIGHTS
ENGINE
ALTERNATOR
POSITION
"1"
Battery 1
Provides
Starting Power
Battery 1
Provides Power for
Accessories and Lights
Charges
Battery 1
POSITION
"2"
Battery 2
Provides
Starting Power
Battery 2
NA
Charges
Battery 2
"BOTH"
POSITION
BOTH Batteries
Provide
Starting Power
BOTH Batteries Provide Power for
Accessories and Lights (not
advised unless engine is running)
Charges
BOTH Batteries
BATTERY
SWITCH
POSITION
"1"
POSITION
"2"
POSITION
"BOTH"
POSITION
"OFF"
STAR-
BOARD
ENGINE
BATTERY
SWITCH
Battery Bank 1
Provides Port Engine
Starting Power & Alter-
nator Charging
Battery Bank 2
Provides Port Engine
Starting Power & Alter-
nator Charging
Connects Battery
Bank 1 & 2
Provides Port Engine
Starting Power & Alter-
nator Charging
Prevents
Port Engine
Start/Run
PORT
ENGINE
BATTERY
SWITCH
Battery Bank 1
Provides Starboard
Engine Starting Power,
Alternator Charging &
Power For Accesso-
ries & Lights
Battery Bank 2
Provides Starboard
Engine Starting Power,
Alternator Charging &
Power for Accessories
& Lights
Connects Battery
Bank 1 & 2
Provides Starboard
Engine Starting Power,
Alternator Charging &
Power For Accessories
& Lights
Prevents
Starboard
Engine Start/
Run
Since your boat’s batteries were installed by your dealer, the battery switch positions listed
below may vary. Make sure your selling dealer fully explains how to use the battery switches.
NOTICE
