Center Console Models • Owner’s Manual Supplement Chapter 5: Controls & Gauges
Trim Tabs (2103 & 2503 Only)
• Before using the trim tabs, read the trim
tabs’ owner’s manual.
• The trim tabs are controlled by two
rocker switches at the helm.
TRIM TAB SWITCHES
TRIM TAB SWITCHES
TRIM TAB (TYPICAL)
2103 HELM VIEW
2503 HELM VIEW
TRANSOM
