Trophy 1703 - 1903 Deck Views

15
Center Console Models • Owner’s Manual Supplement Chapter 3: Locations
1903 Deck Views
VENTED FUEL FILL
DECK FITTING
CLEAT
HORN
FISHING ROD
STOWAGE
GRAB
RAIL
CLEAT
CLEAT
BOARDING
LADDER
GRAB RAILS
CLEAT
ALL-ROUND
LIGHT SOCKET
BAITWELL
MOTOR WELL
DECK PLATE
FUEL LINE
TO ENGINE
AERATOR
VENT
SEAWATER
WASHDOWN
(IF EQUIPPED)
COOLER
(IF EQUIPPED)
FISH BOX
ROD HOLDER
ROD HOLDER
FUEL TANK
DECK PLATE
MOTOR WELL BOOT
AERATOR
CONTROL
VALVE
BOW LIGHT
