24
Chapter 3: Locations Center Console Models • Owner’s Manual
Supplement
Baitwell/Seawater Washdown Intake Pump - 1703 &
1903: Located under the port transom seat.
Bailtwell/Seawater Washdown Intake Seacock - 1703
& 1903: Located under the port transom seat.
Baitwell/Seawater Washdown Y-Valve (If Equipped) -
1703 & 1903: Located under the port transom seat.
Battery - 1703 & 1903: Located under the
starboard transom seat.
Battery Switch - 1703 & 1903: Located
under the starboard transom seat.
Batteries - 2103:
• Located under the leaning post seat.
• Access by opening the leaning post seat
and removing the storage bins.
Battery Switches - 2103:
• Located under the leaning post seat.
• Access by opening the leaning post seat.
PORT TRANSOM SEAT
BATTERY
BATTERY SWITCH
STORAGE
BINS
BATTERY
SWITCH
