30
Chapter 3: Locations Center Console Models • Owner’s Manual
Supplement
Freshwater Fill Deck Fitting (If Equipped)- 2103:
Located on the starboard aft deck.
Freshwater Fill Deck Fitting (If Equipped) - 2503:
Located on the port deck.
Fuel Tank - 1703 & 1903: Access through the
cockpit floor deck plate.
Fuel Fill Deck Fitting - 1703 & 1903: Located
on the starboard aft deck.
FRESHWATER FILL
DECK FITTING
FRESHWATER FILL
DECK FITTING
COCKPIT FLOOR
DECK PLATE
FUEL FILL
DECK FITTING
