Troxler ICO 4740 User Manual

ICO 1-7
2. The unbreakable steel hearth plate (not shown)
provides even distribution of heat beneath the sample
baskets.
3. The basket cover fits over the sample baskets.
4. The stackable sample baskets (2) hold the HMA sample
for burning.
5. The catch pan catches aggregate particles that may fall
through the bottom of the sample basket(s).
6. The basket carrier provides added safety when moving
the sample basket assembly in and out of the oven.
7. The sample safety cage (not shown) shields the hot
sample basket assembly while the asphalt sample cools.
8. The soft-bristled brush (not shown) is used to brush
soot from the turbine blades of the oven’s exhaust fan
when cleaning the exhaust plenum box.
9. Insulated gloves1 (not shown) protect hands and
forearms when moving the heated sample basket(s).
10. The Troxler ICO NCAT Oven (Model 4740) Manual of
Operation and Instruction (not shown) details how to
operate and maintain the oven.
1 Operators should verify that the insulated gloves meet local safety laws and
specifications.
