TRUE ICE SERVICE MANUAL

TEC_TM_198 | REV. A | EN 03/26/2024 Page 25 of 96

truemfg.com

Component Identification (cont.)

22" Top View

Water Circuit

Condenser Fan Motor Condenser Fan Motor

Condenser Access Panel

Biozone/UV System

Water Pump Motor

Sump Tank

3/4" FPT Drain

Drain Valve

1/2" FPT Water Inlet

T3 Temperature Probe

Water Level Sensor

Water Distributor

Inlet Water Valve

Inlet Water Line

Water Fill Line
