TRUE ICE SERVICE MANUAL truemfg.com
TEC_TM_198 | REV. A | EN
P#857284
03/26/2024 Page 40 of 96
Adjust Ice Thickness
Watch at least three cycles and confirm that the bridge thickness is correct, (approximately 1/8" (3.18 mm) as shown in fig. 1).
The bridge thickness is set at the factory. To adjust, please see instructions below.
Ice Machine Adjustments (cont.)
Fig. 1. The ice bridge holds the ice cubes together.
1/8"
(3.18 mm)
1. In the upper right corner of the screen, press Menu .
2. In the Menu screen, press Ice Thickness
.
3. In the Ice Thickness screen, adjust the ice size as needed.
The ice machine is factory-set at 0 for the optimal production
of pounds of ice per day.
º
For thinner ice, press the +/- key and enter a
number 1-6. -6 is the thinnest setting.
º
For thicker ice, enter a number 1-6. 6 is the
thickest setting.
4. After setting the ice size, press okay. The display will return to
the MENU screen.
