TRUE ICE SERVICE MANUAL
TEC_TM_198 | REV. A | EN 03/26/2024 Page 49 of 96
truemfg.com
Maintenance & Cleaning (cont.)
Panel Removal
1. Remove the front panel screws. Then, open the front panels. See fig. 1.
NOTICE ›
Panels cannot be removed without opening the front panels.
2. Carefully lift the front of the top panel. Then, slide the top panel towards the ice machine's rear and lift the panel. See fig. 2.
3. Remove the side panel's rear screw. See fig. 3.
4. Unfasten the side panel's bottom fasteners. Then, lift the side panel. See fig. 4.
Fig. 1. Front panel screw locations. Fig. 2. Lift the front edge, slide the top panel back,
then lift to remove.
Fig. 3. Remove the screw, pull panel from adhering
tabs, then lift to remove.
1
1
2
2
3
