Air-Cooled Ice Machine Specifications & Performance Data (cont.)
TCIM-522-HA1-A/TI-522-MA-S1-A
AC Supply Voltage (V/Hz/Ph) 115/60/1
Amperage [5 min Freeze AT 104˚F (40˚C) / WT 80˚F (27˚C) 8.5
Minimum Circuit Ampacity 15
Maximum Fuse Size 15
Electrical Consumption (kWh/100lb) [AT 90˚F (32˚C) / WT 70˚F (21˚C) 4
Water Consumption (gal/100lb) [All Ambients] 14
Batch Size [lb(kg)] 5-5.4 (2.2-2.4)
Refrigerant [oz(g)] 4.3 (121.9)
Performance Data Sheet
Air Temp
(F˚/C˚)
Water Temp (˚F/C˚)
50/10 70/21 90/32
Ice Production in 24 hours
lb/day - kg/day
70/21
80/27
90/32
100/38
556
545
535
524
253
248
243
238
515
511
508
485
234
232
231
221
473
465
455
447
215
211
207
203
Electric Consumption
Watts
70/21
80/27
90/32
100/38
825
861
892
933
854
875
896
966
883
921
956
999
Freeze Time
mm:ss
70/21
80/27
90/32
100/38
11:4 0
12:02
12:24
12:46
12:43
12:45
12:48
13:55
13:46
14:12
14:39
15:05
Harvest Time
mm:ss
70/21
80/27
90/32
100/38
01:20
01:13
01:06
00:59
01:13
01:07
01:00
00:55
01:07
01:02
00:56
00:50
Head Pressure
PSIG - kPa
70/21
80/27
90/32
100/38
208
221
234
247
1436
1525
1616
1705
214
220
226
254
1478
1517
1556
1754
220
234
248
262
1519
1613
1710
1803
Suction Pressure
PSIG - kPa
70/21
80/27
90/32
100/38
40
41
42
43
277
283
289
294
43
43
43
46
300
300
300
320
47
48
49
50
325
332
339
345
Total Heat of Rejection from Condenser 7730 BTU/hr [AT 90˚F (32˚C) / WT 70˚F (21˚C)]
