Air-Cooled Ice Machine Specifications & Performance Data
TCIM-530-HA1-A/TI-530-MA-S1-A
AC Supply Voltage (V/Hz/Ph) 115/60/1
Amperage [5 min Freeze AT 104˚F (40˚C) / WT 80˚F (27˚C) 8.1
Minimum Circuit Ampacity 15
Maximum Fuse Size 15
Electrical Consumption (kWh/100lb) [AT 90˚F (32˚C) / WT 70˚F (21˚C) 3.68
Water Consumption (gal/100lb) [All Ambients] 14.8
Batch Size [lb(kg)] 4.85-5.15 (2.2-2.35)
Refrigerant [oz(g)] 5.25 (149)
Performance Data Sheet
Air Temp
(F˚/C˚)
Water Temp (˚F/C˚)
50/10 70/21 90/32
Ice Production in 24 hours
lb/day - kg/day
70/21
80/27
90/32
100/38
586
579
571
563
266
263
260
256
552
541
529
518
251
246
241
235
517
502
488
473
235
228
222
215
Electric Consumption
Watts
70/21
80/27
90/32
100/38
791
805
819
833
824
851
877
903
856
896
936
976
Freeze Time
mm:ss
70/21
80/27
90/32
100/38
10:46
11: 01
11:17
11:4 0
11:18
11:47
12:17
12:46
11:50
12:34
13:17
14:01
Harvest Time
mm:ss
70/21
80/27
90/32
100/38
01:33
01:10
00:57
00:50
01:15
01:05
00:55
00:48
01:08
01:00
00:53
00:46
Head Pressure
PSIG - kPa
70/21
80/27
90/32
100/38
197
200
205
210
1356
1379
1413
1448
204
215
225
235
1407
1482
1549
1620
211
227
243
260
1458
1565
1675
1790
Suction Pressure
PSIG - kPa
70/21
80/27
90/32
100/38
38
39
40
41
265
269
279
283
41
41
42
43
283
283
293
296
45
46
47
49
311
317
324
335
Total Heat of Rejection from Condenser 7600 BTU/hr [AT 90˚F (32˚C) / WT 70˚F (21˚C)]
