TRUE ICE SERVICE MANUAL truemfg.com
TEC_TM_198 | REV. A | EN
P#857284
03/26/2024 Page 52 of 96
A. Water Curtain: Remove by placing one hand over the top lip of
the curtain and the other hand on the side of the curtain. Gently
flex the curtain on the side toward the center while gently pulling
the top outward.
B. Damper: Remove by pushing the damper down until horizontal,
pull forward gently until it stops and then push down until it stops
and pull forward.
C. Sump: Reach under the sump and pull off the drain hose. Then
place fingers between the left or right bulkhead wall and the side
of the sump. Place the other hand over the lip of the sump. Push
the sump with your fingers toward the opposite bulkhead wall
while pulling the sump n the same direction with your hand until
it comes out of the snap bracket. Repeat the process on the other
side and remove the sump.
D. Evaporator Area Cover: Remove by pushing up from the inside
of evaporator section.
E. Water Distributor: Remove by grabbing the two distributor
tabs and lifting up slightly then pull forward.
Maintenance & Cleaning
Parts Removal
Descaling
If necessary, cancel the descaling or sanitizing sequences by
pressing cancel
. However, the sequences cannot be cancelled
after cleaner or sanitizer has been added to the sump and OK has
been pressed.
1. Remove all ice from the bin (or dispenser if applicable).
2. Loosen the front panel screws and open the front panel.
3. In the home screen press CLEAN
.
4. Press DESCALE.
