- 23 -
3.2.4 Charging the Battery by 4-bay Printer Charger (Optional)
1. Plug the power adapter of the charger into a properly grounded outlet and plug the
charger connector to a charger DC socket.
2. Install the printer onto the charger at the correct angle and direction as shown below.
Note: To avoid damage, DO NOT install the printer at the angle shown below.
3. Turn on the power button of charger. It will start charging. (The LED on charger will turn
on.)
4. When charging, the battery status LED indicator on the printer turns solid amber. When
fully charged, the printer LED indicator turns off. It will stop charging automatically after
the battery is fully charged.
To Next Page
