TSC Alpha-30L Series User Manual

- 46 -
4.4 Sensor
This "Sensor" option is used to calibrate the selected media sensor. We recommend calibrate the sensor
before printing when changing the media.
Item
Description
Default
Auto Calibration
This option is used to set the media sensor type and
calibrate the selected sensor automatically. Printer will
feed 2 to 3 gap labels to calibrate the sensor sensitivity
automatically.
N/A
Manual setup
In case “Automatic” cannot apply to the media, please
use “Manual” function to set the paper length and
gap/bline size then scan the backing/mark to calibrate
the sensor sensitivity.
N/A
Threshold Detect
This option is used to set sensor sensitivity in [Fixed] or
[Auto].
Auto
Maximum Length
This option is used to set the maximum length for label
calibration.
152 mm
BMark Transmitter
This option is used to set the sensor to detect the black
mark on the printed side of the paper or the black mark
on the back side of the paper.
Print Side
Advanced
This function can set the minimum paper length and
maximum gap/bline length for auto-calibrate the sensor
sensitivity.
Min. Paper: 0 mm
Max. Gap/Mark: 0mm
Sensor
Auto Calibration
Gap
Black Mark
Continuous
Preprint
Manual Setup Standard
Gap
Black Mark
Continuous
Threshold Detect
Auto
Fixed
Maximum Length
BMark Transmitter
Print Side
Back Side
Advanced
Min. Paper
Max. Gap/Mark
