- 40 -
4. LCD Menu Function
The Alpha-30L/ Alpha-40L series offer the LCD panel to further enhance its capabilities to meet the demands
of a wide range of printing solutions. This feature includes LCD control panel, 4 buttons and 2 LED display.
Please press the “Menu” button to enter the setting menu.
4.1 How to Use the LCD to Set the Printer
Press the key to enter the menu list as following shown. You can use this 4 navigational keys
and soft keys to scroll, select, enter or return the menu.
Left soft key
(Menu status)
The label on the header of the UI will explain the function
for left soft key.
Right soft key
(Menu status)
The label on the header of the UI will explain the function
for right soft key.
Navigational keys
(Menu status)
Used to select items, menu selection, and navigation in
the UI.
Enter the menu list ( the Menu is locked and a password is required.)
Enter cursor (be marked in green) located option
Scroll down button/ Scroll up button
To Next Page
