TSC Alpha-30L Series User Manual

- 51 -
4.8 Diagnostic
Item
Description
Print Config.
This feature is used to print current printer configuration to the label. On the
configuration printout, there is a print head test pattern, which is useful for checking if
there is any dot damage on the print head heater element.
Self-test printout
Model name
F/W version
Firmware checksum
Printer S/N
TSC configuration file
System date
System time
Printed mileage (meter)
Print head bad dot
Print speed (inch/sec)
Print darkness
Label size (inch)
Gap distance (inch)
Gap/black mark sensor intension
Code page
Country code
Standby time
Sleep time
Print darkness
Print speed (inch/sec)
Label size
Control prefix
Format prefix
Delimiter prefix
Printer power up motion
Printer head close motion
Diagnostic
Print Config.
Dump Mode
Print Head
Display
Sensor
Diag Gap
Diag Black Mark
