TSC Alpha-30L Series User Manual

- 45 -
Item
Description
Default
Darkness
Use this item to setup printing darkness. The available setting is from 0 to
30, and the step is 1. You may need to adjust your density based on
selected media.
16
Print Speed
Use this item to setup print speed. The each increase or decrease is 1 ips.
Available setting is from 1 to 6.
3 ips
Tear Off
This item is used to fine tune media stop location. Available setting value is
from “+” to “-” or “0” to “9”.
0 dot
Print mode
This item is used to set the print mode. There are 2 modes as below,
Printer Mode
Description
Tear Off
Next label top of form is aligned to the print
head burn line location.
Peeler Off
Enable the label peel off mode.
Tear Off
Print Width
This item is used to set print width. The available value is from “0” to “9”.
832 dot
List Fonts
This feature is used to print current printer available fonts list to the label.
The fonts stored in the printer’s DRAM, Flash or optional memory card.
N/A
List Images
This feature is used to print current printer available images list to the label.
The images stored in the printer’s DRAM, Flash or optional memory card.
N/A
List Formats
This feature is used to print current printer available formats list to the label.
The formats stored in the printer’s DRAM, Flash or optional memory card.
N/A
List Setup
This feature is used to print current printer configuration to the label.
N/A
Control Prefix
This feature is used to set control prefix character.
7E(~)
Format Prefix
This feature is used to set format prefix character.
5E(^)
Delimiter Char
This feature is used to set delimiter character.
2C(,)
Media Power
Up
This option is used to set the action of the media when you turn on the
printer.
Selections
Description
Feed
Printer will advance one label
Calibration
Printer will calibration the sensor levels,
determine length and feed label
Length
Printer determine length and feed label
No Motion
Printer will not move media
No Motion
Head Close
This option is used to set the action of the media when you close the print
head.
Selections
Description
Feed
Printer will advance one label
Calibration
Printer will calibration the sensor levels,
determine length and feed label
Length
Printer determine length and feed label
No Motion
Printer will not move media
Feed
Label Top
This option is used to adjust print position vertically on the label. The range
is -120 to +120 dots.
0 dot
Left Position
This option is used to adjust print position horizontally on the label. The
range is -9999 to +9999 dots.
0
Reprint Mode
When reprint mode is enabled, you can reprint the last label printer by
pressing [UP] button on printer’s control panel.
Disable
Format
Convert
Selects the bitmap scaling factor. The first number is the original dots per
inch (dpi) value; the second, the dpi to which you would like to scale.
None
