TSC TTP-244 Pro Series User Manual

- 6 -
1.6 Media Specifications
Media Specifications
Label roll capacity
110 mm (4.33”) OD
Media core diameter
25.4 ~ 76.2 mm (1” ~ 3”)
Media type
Continuous, die-cut, black mark, External fan-
fold, notched
Media wound type
Outside wound
Media width
25.4 ~ 112 mm (1.0” ~ 4.4”)
Media thickness
0.06 ~ 0.25 mm (2.36 ~ 9.84 mil)
Label length
10 ~ 2,286 mm (0.39” ~ 90”)

TSC TTP-244 Pro Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
Processor	32-bit RISC CPU
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0
Label Width	1 inch to 4.49 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External universal switching power supply
Operating Temperature	5 ~ 40°C (41 ~ 104°F)
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
